VU panels of A320
What is vu panel?
VU is generally used in aviation to define the location of panels, groups of CBs panels etc. VU makes the easiest way to find and locate the the particular panels within the Aircraft. VU of the Airbus A320 series Aircrafts are as follows. I'm try to explain the all VUs of the Airbus for better understanding. I will try to define each VU in detailed, after some time later you are able to view details by clicking on the VUs.
1VU – L FWD CONSOLE
2VU – L INSTRUMENT PNL
6VU – R INSTRUMENT PNL
7VU – R FWD CONSOLE
8VU – SWITCHING PNL/ CONTROL PANEL
10VU – MAIN INSTRUMENT PANELS
11VU – CENTER PEDESTAL
13VU - Flight Control Unit
15VU – FOURTH OCCUPANT JACK PNL
16VU – F/O HAND MIC PNL /JACK PANEL
17VU – CAPT HAND MIC PNL/JACK PANEL
18VU – CONTROLLER-SIDE STICK, F/O
19VU – CONTROLLER-SIDE STICK, CAPT
20VU – OVERHEAD PNL
21VU – EVAC/EMERGENCY /CALL PANEL
22VU – CARGO HEAT PANEL
23VU – FLIGHT CONTROL PANEL
24VU – FLIGHT CONTROL PANEL
25VU – ANTI-ICE/CAB PRESS/LIGHTS PANEL
27VU – CONTROL PANEL
30VU – AIR COND CONTROL PANEL
35VU – ELECTRIC CONTROL PANEL
40VU – HYD/FUEL PNL
41VU – ADIRS MSU PANEL
45VU – DOORS PANELS
48VU – AUDIO SWITCHING PANEL
49VU – OVERHEAD C/B PNL
50VU – MAINTENANCE PNL
51VU – FUEL PNL
52VU – FMS LOAD PNL
54VU – READING LT PNL
55VU – ELT PNL
56VU – CAMERA CONTROL PNL
60VU – F/O JACK PNL
61VU – CAPT JACK PNL
62VU – THIRD OCCUPANT JACK PNL
63VU – AVIONICS COMPARTMENT JACK PNL
64VU – THIRD OCCUPANT JACK PANEL
65VU – CAPT ADDITIONAL JACK PANEL
66VU – F/O ADDITIONAL JACK PANEL
70VU – ANN LT TEST UNIT
80VU – AFT ELECTRONICS RACK
81VU – SHELF
82VU – SHELF
83VU – SHELF
84VU – SHELF
85VU – SHELF
86VU – SHELF
87VU – SHELF
88VU – SHELF
90 VU –
91VU – SHELF
92VU – SHELF
93VU – SHELF
94VU – SHELF
95VU – SHELF
96VU – SHELF
101VU – L SIDE CONSOLE
103VU – RELAY BOX
105VU – POWER CENTER-BATTERY
106VU – POWER CENTER-AC/DC EMERGENCY
107VU – CONTACTOR BOX
108VU – EXT PWR PNL
109VU – SHELF-WEATHER RADAR
110VU – RUD TRIM/PARKING BRK PNL
111VU – FLOOD LT/INTEG LTG PNL
112VU – FLOOD LT PNL/LIGHT/AIDS PANEL
113VU – VIP COM PANEL
114VU – FLAPS PNL
115VU – ENG START PANEL
117VU – DATA LOADER PANEL
119VU – COCKPIT DOOR PANELS
120VU – REAR PNL
121VU – REAR C/B PANEL
122VU – REAR C/B PNL
123VU – REAR C/B PNL
124VU – REAR C/B PNL
125VU – REAR C/B PNL
130VU – F/O GLARESHIELD PNL
131VU – CAPT GLARESHIELD PNL
180VU – HAND GRIP-SIDE STICK, F/O
186VU – PLATE-RELAY
187VU – PLATE-RELAY
188VU – PLATE-RELAY
191VU – HAND GRIP-SIDE STICK, CAPT
200VU – PLATE-GALLEY CONTACTOR
210VU – LEVER ASSEMBLY-THROTTLE CONTROL, R
211VU – LEVER ASSEMBLY-THROTTLE CONTROL, L
301VU – CPT PFD/ND CONTROL PANEL
400VU – R CENTER INSTRUMENT PNL
401VU – L CENTER INSTRUMENT PNL
402VU – LANDING GEAR CTL & IND PNL
403VU – TERR ON ND PANEL
452VU – R DOME LT PNL
453VU – L DOME LT PNL
500VU – FO PFD/ND CONTROL PANEL
502VU – FOOT REST, CAPT
502VU – FOOT REST, F/O
619VU – L REMOTE ATC
620VU – R REMOTE ATC
700VU – R SIDE CONSOLE
704VU – THIRD OCCUPANT CONSOLE
800VU – CTL PNL-REFUEL/DEFUEL
802VU – ACT RELAY PANEL
2000VU – C/B PNL
2001VU* – C/B PNL
2004VU – LATCH-DOORSILL
2005VU – FAN ASSY-RADIO ALTIMETER TRANSCEIVER 1
2006VU – VALVE PNL-CARGO COMPT DOOR
2007VU* – CAPACITY-UNIT
2010VU* – ADAPTER-DEU
2011VU* – ADAPTER-DEU
2014VU* – ADAPTER-DEU
2015VU* – ADAPTER-DEU
2020VU – CTL PNL-CARGO LOADING SYSTEM
2021VU – CONTROL PANEL-WASTE WATER LEVEL IND
2022VU – CTL PNL-WASTE WATER LEVEL IND
2023VU – CTL PNL-WATER QUANTITY INDICATING
2024VU – CTL PNL-CARGO COMPT LIGHTING
2025VU – CTL PNL-WHEEL WELL LIGHT/INTERPHONE
2027VU* – CTL PNL-CARGO COMPT DOOR LOCKING INDICATING
2036VU* – PSIU-LAVATORY
2037VU* – PSIU PNL-ATTND
2038VU* – PCB-PSIU
2039VU* – PSIU
2040VU* – PSIU
2042VU – PSIU
2043VU – MEDICAL OUTLET PANEL
2062VU* – SW PNL-LIGHT, SINGLE
2063VU – SW PNL-LIGHT, DOUBLE
3700VU – INFO PNL-PAX
3701VU – INFO PNL-PAX
3714VU – CEILING PANEL
Avionics compartment electronic rack
- The electronic racks (90VU and 80VU)
- The Weather Radar shelf (109VU)
- The relay and contactor boxes (103VU and 107VU)
- The annunciator light test unit (70VU)
- AC and DC emergency power center (106VU)
